Recomended for first user iREAP POS
The iREAP POS smart cashier application now has support for the Bellav Z80 Bluetooth Printer. With this support, you can carry out your transaction activities more flexibly, by printing a logo and receipt for your customers anywhere and anytime.
|Bluetooth Printer Bellav Z80|
|Thermal / DOT Metrix||Thermal|
|Paper Width||80 mm|
|Paper Type||Thermal Paper|
|Location to save the Logo||App|
Turn on the Bellav Z80 bluetooth printer machine until the indicator light turns on
Pair the device that has the iREAP POS application to the Bellav Z80 printer via Bluetooth
Enter the pin as specified before (Default pin: 0000 or 1234)
If you are already connected, open the iREAP POS application on the device that is connected to the Bellav Z80 printer
Login by entering the Username and Password that have been previously registered
On the main page, select "Setting and Parameters"
Scroll down until you find the "Printer Model" menu, click on the menu
Select the printer model you want to choose (BellaV Z80 printer)
The notification will appear as shown below, click OK
Press "Bluetooth Printer Name", then select the printer, after selecting press OK (The second picture is a simulation for selecting the bluetooth printer you want to use that is already registered in the application)
After doing all the steps above, you can scroll down to provide a checklist on the "Print Logo" menu
Press the "Select Logo" menu to select the image that you want to print on the receipt when you print later. When you make a logo selection, please ensure that the size of the chosen logo image is 360px so that the logo can print well
If the printer settings have been completed, you can continue to use iReap POS to record your sales transactions. Details about recording sales transactions can be seen in the following link :
The screen will bring up a List of Sales / Return that has been made previously and the machine will automatically print the receipt along with the logo that was selected in the previous step.
